Diamond 8 Centre
|
|
 |
|
| DIAMOND 8 CENTRE |
Bass Tweeter |
2 x 130mm KEVLAR, 25mm silk dome. |
Recommended Amp. Power |
20 - 120Wrms |
Nominal Imp. |
6 ohm |
Sensitivity |
88dB for 2.83v at 1m |
Frequency Range. |
60Hz - 20kHz |
Crossover Frequency |
3kHz |
Size (HxWxD) |
176 x 451 x 181mm |
|
|
|
|
.................................................... |
|
Diamond 8 DFS
|
|
|
|
| DIAMOND 8 DFS |
Bass Tweeter |
130mm x 2, 25mm silk dome x 2 |
Recommended Amp. Power |
20 - 120Wrms |
Nominal Imp. |
6 ohm |
Sensitivity |
90dB 1W @1m |
Frequency Range. |
70Hz - 20kHz |
Crossover Frequency |
3kHz |
Size (HxWxD) |
900 x 213 x 295mm |
|
|
|
|
.................................................... |
|
Diamond 8.1
|
|
|
|
| DIAMOND 8.1 |
Drivers |
130mm KEVLAR, 25mm silk dome |
Recommended Amp. Power |
20 - 120Wrms |
Nominal Imp. |
6 ohm |
Sensitivity |
86dB for 2.83v at 1m |
Frequency Resp. |
55 to 20kHz |
Size (HxWxD) |
296 x 198 x 181mm |
|
|
|
|
.................................................... |
